AC.100.7813
Qty
1.Voltage (Rated / Operating)：
Operating high voltage range: 220V ~ 420V DC
Standard rated operating voltage: 320V / 350V DC
2.Cooling Capacity (Typical Operating Conditions)：
Rated power consumption: 4.8kW (continuous power consumption under stable constant temperature operation)
Peak operating power consumption: Max. 5.3kW (full-load operation for rapid cooling upon startup)
3.Rotational Speed：
Normal dynamic operating speed: 1200 ~ 5800 r/min
Maximum safe rated limit speed: 8500 r/min
4.Drive: DC Inverter Motor
5.Oil&Refrigerant：HFC-134a/HFO-1234y ND-OIL 11
6.OE：KT042400-2510/8110004DSV0100
